The Lithium Box 100/40
with 375VA Inverter

  • 100Ah RV Lithium Systems Lithium (LiFePO4) Battery with Cell Balancing and Cell Protection

  • Victron BMV 712 Bluetooth Battery Meter Display.
    Read the battery meter from the convenience of your smart phone
    Displays the battery’s voltage, amps in or out, amp hours consumed, time to go until flat, and actual State of Charge (SOC) as a percentage.

  • REDARC BCDC 1240D Vehicle 40A DC to DC Charger with Blue 50A  Anderson Plug Input, protected by cell protection and 40A MPPT Solar Charger with Red 50A Anderson Plug Input protected by cell protection

  • Victron Phoenix 375VA Inverter

  • Master Battery Switch

  • Automatic 100A Low Battery State of Charge or Voltage Disconnect of accessory power sockets and Automatic Reconnect once the battery has received adequate charge

  • Internal Fusing and Output Short Circuit Protection

  • 2 x 50A (max) Grey Anderson Plug Output

  • 2 x Anderson Plug for Power Output on the rear (16A max each)

  • 2 x Accessory (Cig) Sockets

  • Twin 2.1A USB Socket

  • 1 x Waeco/Engel Socket

  • A Victron Energy 240V IP65 Battery Charger connection for optional 240 volt charging (5 to 15A max).

  • A Smart Alternator Ignition Wire Input or Loop Connection.

  • Weighs in at only 24kgs
    Measures 480 x 160 x 405mmH

The Lithium Box with 375VA Victron Inverter
