The Lithium Box 100/40
Barista

• 100Ah RV Lithium Systems Lithium (LiFePO4) Battery with Cell Balancing and Cell Protection

• Victron BMV 712 Bluetooth Battery Meter Display.
  Read the battery meter from the convenience of your smart phone
  Displays the battery’s voltage, amps in or out, amp hours consumed, time to go until flat, and actual State of Charge (SOC) as a percentage.

• REDARC BCDC 1240D Vehicle 40A DC to DC Charger with Blue 50A  Anderson Plug Input, protected by cell protection and 40A MPPT Solar Charger with Red 50A Anderson Plug Input protected by cell protection

• Victron Phoenix 1200VA Inverter.
  This will run a Coffee Pod Machine with Milk Frother.

• Master Battery Switch

• Internal Fusing and Output Short Circuit Protection

• 1 x 240V Outlet Socket on front face

• 275A Twin Load BCU 175A BCU for Inverter and 100A BCU for all 12v Output Sockets.  Automatic Low Battery SOC or Voltage Disconnect of Inverter and  accessory power sockets and automatic reconnect once the battery has received adequate charge.

• 2 x 12V Cig Accessory Sockets

• 1 x Engel / Waeco Fridge Sockets

• 1 x Plug in dual USB plug (can be plugged into one of the Cig sockets)

• 2 x 50 A Grey Anderson Plug Outputs on front of TLB (50a max each)

• A Smart Alternator Ignition Wire Input or Loop Connection.

• Weighs in at only 24kgs
  Measures 470 x 210 x 260mmH
