The Lithium Box 200/40

  • 200Ah RV Lithium Systems Lithium (LiFePO4) Battery with Cell Balancing and Cell Protection

  • Victron BMV 712 Bluetooth Battery Meter Display.
    Read the battery meter from the convenience of your smart phone
    Displays the battery’s voltage, amps in or out, amp hours consumed, time to go until flat, and actual State of Charge (SOC) as a percentage.

  • REDARC BCDC 1240D Vehicle 40A DC to DC Charger with Blue 50A Anderson Plug Input, protected by cell protection and 40A MPPT Solar Charger with Red 50A Anderson Plug Input protected by cell protection

  • Master Battery Switch

  • Automatic 100A Low Battery State of Charge or Voltage Disconnect of accessory power sockets and Automatic Reconnect once the battery has received adequate charge

  • Internal Fusing and Output Short Circuit Protection

  • 2 x 50A (max) Grey Anderson Plug Output

  • 2 x Anderson Plug for Power Output on the rear (16A max each)

  • 2 x Accessory (Cig) Sockets

  • 2 x Engel/Waeco Sockets

  • 1 x Twin 2.1A USB Socket

  • A Victron Energy 240V IP65 Battery Charger connection for optional 240 volt charging (5 to 15A max).

  • A Smart Alternator Ignition Wire Input or Loop Connection.

  • Weighs in at only 29kgs
    Measures 425 x 152 x 325mmH
